Eachine TX801 video transmitter with 8 power levels

An interesting new video transmitter appeared in the market – Eachine Tx801. It is 5.8GHz video transmitter with a whole bunch of the features. First of all it has 8(!) switchable power levels – 0.01, 5, 25, 50, 200, 400, and 600mW. I don’t know the other video transmitter on the market with 8 power levels. This allows you to choose the required signal strength according to the situation – if you are flying with copters in competition mode, then you migth choose 25-50mW to minimize interference to others, 200mW for casual flying  and to choose 400-600mW for long range flights. This VTX has total of 72 channels (8 groups by 8 channels). Can be tuned to any known receiver/goggles. It even has an onboard microphone to transmit the surrounding audio, for those who lke to hear the wind and motors roaring.

I have high anticipations for this transmitter. MultirotorGuide will be testing and reviewing this transmitter, so stay tuned!

Can be purchased @ Banggood: https://www.banggood.com/Eachine-TX801-5_8G-72CH-0_01MW5MW25MW50MW100MW200MW400MW600MW-Switched-AV-VTX-FPV-Transmitter-p-1147691.html

Description :
Brand Name : Eachine
Item Name : TX801 Transmitter
Antenna Gain: 3Dbi
Antenna Conenctor : RP-SMA
Frequency:5325-5945MHZ
Channel : 72CH
Transmitting Power: 0.01MW/5MW/25MW/50MW/100MW/200MW/400MW/600MW Switchable
Video Format:NTSC/PAL
Working Current: (MAX)7V-550mA
;12V-300mA
;24V-160mA”
Audio Bandwidth : 6.5MHZ
Video Bandwidth: 18MHZ
Audio Carrier : 1Vp-p(1KHZ)
AF Input Impedance : 10KΩ
Working Voltage : 7-24V
Output Voltage : 5V
Weight :7.3g
Size :28*20*8MM
